Kyocera KJ4B-0300-RO6DS-STD1 Print Head


Basic Info.

  • Brand:  Kyocera
  • Model: KJ4B-0300-RO6DS-STD1
  • nk Type: solvent/UV
  • Dimensions: 200 × 25 × 59.3mm
  • Dry Weight: 420g
  • Total Nozzles: 2.656
  • Nozzle Pitch: 0.042mm
  • Standard Resolution: 600 x 600 dpi
  • Print Width: 108.25mm
  • Max. Drive Frequency: 30kHz
  • Drop Volume: 5, 7, 12 and 18pl
  • Original or Not: double channel
  • Max. Sprint Speed: 75m/min
  • Optimum Ink Viscosity: 5.0 – 6.0 mPa*s

*For more information about this printer part, you can send us an inquiry.

Printer Compatibility

Product Details

This Kyocera KJ4B is designed for high speed printing of water-based inks. It is a 600 dpi one colour printhead with a maximum drive frequency of 30kHz. It delivers high quality with a small drop volume of 5pl at 75 m/min by making use of 2,656 nozzles arranged across a 108.25 mm wide print swathe with 0.042mm pitch, resulting in 30,000 drops per second. Its unique ink channel design provides a stable ink supply.



Yes.We are wide format printer parts manfacturer and print heads supplier.and ink pump is our main product

Each ink pump has been spot-checked by a superior leader. You are also welcome to visit the company.

We accept the T/T transfer, Western Union, PayPal. Within 2-3 workdays after full payment is received.

Please feel free to contact us, we have the complete range of printer spare parts.
