Starfire 1024LA 80pl Print Head


Basic Info.

  • Brand: Starfire
  • Model Code: LA
  • Active Nozzles:1024
  • Drop Volume:80PL
  • Fire Frequency: Up to 20 kHz
  • Nozzle Plate Technology: Metal
  • Inkjet Operating Temperature Range: Up to 50°C (122°F)
  • OEM Accessible Non-volatile Memory: 64 byte rewriteable
  • Integral Temperature Sensor: Integrated
  • Printhead Heat Type: Integrated heater, thermal transfer
  • Nominal Fluid Viscosity: 8-20 cP (10-14 cP recommended)
  • Compatible Jetting Fluids: UV-curable, organic solvents, and aqueous inks
    This printhead carries a manufacturer’s warranty
  • Country of Origin: Japan

*For more information about this printer part, you can send us an inquiry.

Printer Compatibility

Product Details

The StarFire™ SG1024/LA2Ci is a compact, self-contained unit built to withstand demanding industrial textile and other applications. It uses field proven materials to deliver consistent output over a long service life with continuous ink re-circulation and two-color operation at 200 dots-per-inch. Equipped with a single replaceable metal nozzle plate that is designed to withstand abrasion and resist damage. The unit is compatible with solvent, UV-curable, and aqueous ink formulations.

Each SG1024/LA printhead has two separate ink paths each with 512 independent channels arranged in 4 rows in a single nozzle plate for resolutions up to 200 dpi. All 1024 nozzles can be fired.



Yes.We are wide format printer parts manfacturer and print heads supplier.and ink pump is our main product

Each ink pump has been spot-checked by a superior leader. You are also welcome to visit the company.

We accept the T/T transfer, Western Union, PayPal. Within 2-3 workdays after full payment is received.

Please feel free to contact us, we have the complete range of printer spare parts.
